BAT52系列防爆投光燈(IIB、IIC)


適用范圍
1、1區、2區危險場所。
2、ⅡA、ⅡB類爆炸性氣體環境。
3、可配裝汞燈、高壓鈉燈、金鹵燈。
*要求ⅡC類時請注明。


Application
1、Can be used in Zone 1 and Zone 2 dangerous places.
2、Can be used in ⅡA、ⅡB group explosive atmosphere.
3、Suitable for mercury vapor lamp, high-pressure sodium vapor lamp, metal halide lamp.
*Please note if need Ⅱ C group.

產品特點

1、鑄鋁合金外殼,壓鑄成形,表面噴塑。
2、燈體可在水平安裝或壁式安裝,仰角在45°~90°
內可調。
3、采用側面開蓋,便于更換燈泡。
4、采用桔紋漫反射板,使光線柔和且照射角大。
5、電纜布線。
6、符合GB3836-2000,IEC60079標準要求。

Features
1、Diecasted Al-alloy shell with plastic-sprayed surface.
2、Horizontal mounting or wall installing is available, elevation angle is adjustable
from 45°to 90°.
3、The side is opened, which is easy for installing and maintaining lamp.
4、Adopting reflection plate like orange surface so as to make light soft and
have large range of illumination.
5、Suitable for cable wiring.
6、Suitable for GB3836-2000, IEC60079 standard request.



主要技術參數 Main technical parameters
防爆標志
防護等級
電纜外徑
進線口螺紋
燈座代號
Exde II BT3
Exde II CT3
IP55
10-14
3/4
E40


配用光源 Supplied with lamps
光源類型
目鎮汞燈
高壓汞燈
高壓鈉燈
金鹵燈
額定電壓(V)
220
額定功率(W)
250
175
150
175
250
250
250
450
400
400
400


殼體類型
功率(W)
質量(Kg)
I
150 175
7.5
II
250 100 150
9.3
